Contact plate-system

Our contact plate-system is applied in the transmission of digital and analogue signals, among others in LAN, field bus and Ethernet standard to power transmission especially to small installation spaces.

This system is distinguished by its small installation height and extensive variety of models such as free boreholes up to 950 mm, integrated protection tubes and media distributors for example.

Further features such as the fixture for shaft encoders and high current components are easy to implement. Concentric designs for low installation heights and customer-specific aluminium housings are also possible.


Material contact plates or solid brass rails
Brushes silver contacts
Speed up to 30 rpm
Data transmission Ethernet 100 Mbit/s
Housing aluminium, stainless steel or steel (galvanised or painted)
Protection class up to IP 67
