Pantoraphs series Fb 700 / Fb 800

The Fb 700 series has been deliberately designed with a small number of individual components and guarantees a low weight and very low maintenance costs.

The Fb 800 unifies all the advantages of the Fb 700 and combines them with a high-strength upper arm of steel and a collector head that is movable in the direction of travel with a maintenance-free spring design.

TECHNICAL SPECIFICATION

Speed 120 km/h
Contact force 60 - 120 N (adjustable)
Drive supply Electrical spindle drive
Pneumatical drive
Overhead wire rated voltage up to 1500 V
Rated current up to 2700 A
